Compact Fiberglass Reinforced Plastic (FRP) Continuous Braiding and Winding Pipe Production Line

Machine Overview

The Small FRP Continuous Braiding & Winding Pipe Machine is a compact production line designed for manufacturing small-diameter high-strength fiberglass reinforced plastic (FRP) pipes.

It integrates continuous fiber braiding, resin impregnation, and winding forming technology to produce pipes with excellent strength, corrosion resistance, and lightweight performance. It is especially suitable for small-scale production, laboratory development, and customized pipe manufacturing.

Machine Structure

The machine typically consists of:

· Creel system for fiberglass rovings

· Continuous braiding unit with adjustable braiding angle

· Resin impregnation system for full fiber wet-out

· Forming mandrel system for pipe shaping

· Heating and curing system (electric or infrared)

· Haul-off traction system with stable speed control

· Automatic cutting unit (optional)

· PLC touch-screen control system for full automation

Key Features

· Suitable for small-diameter FRP pipes (typically 10mm–200mm)

· Continuous production with high efficiency

· Uniform braided structure with high mechanical strength

· Excellent corrosion and chemical resistance

· Compact design with small footprint

· Customizable pipe diameter and wall thickness

· Easy operation with high automation level

Applications

· Chemical fluid transport pipelines

· Agricultural irrigation systems

· Laboratory fluid piping systems

· Cable protection conduits

· Small industrial pipeline systems

· Seawater and wastewater treatment systems
